Description
| Code | Description | Dimensions (mm) | Weight | Net | Flour Capacity | Capacity | ||
| a | b | c | kg | m3 | kg | lt | ||
| ASH.07 | Spiral Dough Mixer 380 V | 725x1225x1320 | 550 | 1,17 | 62,5 | 100 | ||
| ASH.08 | Spiral Dough Mixer 380 V | 825x1350x1320 | 800 | 1,48 | 80 | 130 | ||
– Double motorised mixer with fixed bowl.
– Two speed dough mixing arms.
– Timed control panel.
– Emergency stop.
– Stainless steel bowl spiral and knife set
– Switch feature that stops automatically when the lid is opened.
– Ability to knead any kind of dough.
– The boiler can be rotated in two directions.
– Direct water connection system is available.
– The machine can operate manually and automatically and has two time settings.
– Fast and slow operation feature is available.
ASH.07
– Upper Motor:3,5-6 kW 750/1500 D/Dk 380V
– Lower Motor:0,75 kW 750 D/Dk 380V
– Boiler Dimension : 700×410 mm
– Boiler Volume : 157 lt
ASH.08
– Upper Motor: 5,5-7 kW 750/1500 D/Dk 380V
– Lower Motor: 0,75 kW 750 D/Dk 380V
– Boiler Dimension: 800×415 mm
– Boiler Volume: 208 lt
| Code | Description | Dimensions (mm) | Weight | Net | Flour Capacity | Capacity | ||
| a | b | c | kg | m3 | kg | lt | ||
| ASH.07 | Spiral Dough Mixer 380 V | 725x1225x1320 | 550 | 1,17 | 62,5 | 100 | ||
| ASH.08 | Spiral Dough Mixer 380 V | 825x1350x1320 | 800 | 1,48 | 80 | 130 | ||
